109-406

Description

The part number 109-406 is a high-efficiency shaded pole motor designed for various industrial applications, offering reliable performance and durability.

The 109-406 shaded pole motor is engineered for optimal efficiency and longevity in demanding industrial environments. This motor features a robust design that ensures consistent operation, making it suitable for a wide range of applications. With its shaded pole configuration, the motor provides smooth and quiet operation, which is essential in settings where noise reduction is a priority. The motor is built with high-quality materials that enhance its durability and resistance to wear, ensuring a longer service life. Its compact size allows for easy integration into existing systems, while the lightweight design simplifies installation and maintenance. The 109-406 is ideal for applications requiring moderate power output and reliable performance, making it a preferred choice for manufacturers and engineers alike. With its excellent airflow capabilities and efficient energy consumption, this motor stands out as a dependable solution for various industrial needs.
Full Specifications:
a. Frequency: 60 Hz
b. Power Rating: 1/20 HP
c. Voltage: 115 V
d. Motor Type: Shaded Pole
e. Frame Material: Aluminum
f. Bearing Type: Sleeve
g. Enclosure Type: Open
h. RPM: 1550
i. Mounting Type: Foot Mount
j. Weight: 5 lbs
k. Amperage: 1.0 A
l. Noise Level: 40 dB
m. Dimensions: 6.5 x 5.5 x 4.5 inches
n. Airflow: 100 CFM

Applications Used:
a. Ventilation systems
b. Small fans and blowers
c. Cooling equipment
