109-407

Description

The part number 109-407 is a high-efficiency shaded pole motor designed for various industrial applications, providing reliable performance and durability.

The 109-407 shaded pole motor is engineered for optimal performance in a variety of industrial settings. This motor features a robust design that ensures longevity and reliability, making it suitable for continuous operation. With its shaded pole configuration, it offers a simple and effective way to convert electrical energy into mechanical motion, providing smooth and quiet operation. The motor is built with high-quality materials that enhance its durability and efficiency, allowing it to withstand demanding environments. Its compact size and lightweight construction facilitate easy installation and integration into existing systems. The 109-407 is ideal for applications requiring moderate power output and consistent performance, making it a versatile choice for manufacturers and engineers alike. This motor is particularly noted for its low noise level and efficient airflow, which contribute to its suitability in environments where sound and air circulation are critical.
Full Specifications:
a. Frequency: 60 Hz
b. Power Rating: 1/20 HP
c. Voltage: 115 V
d. Motor Type: Shaded Pole
e. Frame Material: Aluminum
f. Bearing Type: Sleeve
g. Enclosure Type: Open
h. RPM: 1550
i. Mounting Type: Foot Mount
j. Weight: 3.5 lbs
k. Amperage: 1.2 A
l. Noise Level: 40 dB
m. Dimensions: 6.5 x 4.5 x 4.0 inches
n. Airflow: 50 CFM

Applications Used:
a. Ventilation systems
b. Small appliances
c. Cooling fans
