736-409

Description

The part number 736-409 is a high-efficiency shaded pole motor designed for various industrial applications, delivering reliable performance and durability.

The 736-409 motor is engineered for optimal efficiency in a variety of industrial settings. This shaded pole motor is particularly suited for applications requiring low starting torque and continuous operation. With its robust construction, the motor features a durable frame material that ensures longevity and resilience against harsh operating conditions. The design incorporates a reliable bearing type that minimizes friction and enhances performance, contributing to a longer lifespan. Its compact dimensions allow for easy integration into existing systems, while the effective airflow design ensures proper cooling during operation. The motor operates at a consistent RPM, making it ideal for applications that require steady speed and reliability. With a focus on energy efficiency, the 736-409 motor meets industry standards, making it a preferred choice for manufacturers seeking to optimize their equipment’s performance.
Full Specifications:
a. Frequency: 60 Hz
b. Power Rating: 1/20 HP
c. Voltage: 115 V
d. Motor Type: Shaded Pole
e. Frame Material: Aluminum
f. Bearing Type: Sleeve
g. Enclosure Type: Open
h. RPM: 1550
i. Mounting Type: Foot Mount
j. Weight: 3.5 lbs
k. Amperage: 1.2 A
l. Noise Level: 50 dB
m. Dimensions: 6.5 x 5.0 x 4.0 inches
n. Airflow: 100 CFM

Applications Used:
a. HVAC systems
b. Exhaust fans
c. Small appliances
