106-509

Description

The part number 106-509 is a high-efficiency shaded pole motor designed for various industrial applications, offering reliable performance and durability.

The 106-509 motor is engineered to meet the demands of industrial environments, providing a robust solution for applications requiring consistent operation and energy efficiency. This shaded pole motor features a compact design, making it suitable for installation in tight spaces while still delivering powerful performance. The motor is constructed with high-quality materials, ensuring longevity and resistance to wear and tear. Its low noise level makes it ideal for environments where sound reduction is essential. With a reliable RPM rating, the 106-509 is capable of maintaining optimal performance under varying load conditions. The motor’s design also facilitates easy mounting, allowing for quick installation and maintenance. Overall, the 106-509 is an excellent choice for businesses looking to enhance their operational efficiency with a dependable motor solution.
Full Specifications:
a. Frequency: 60 Hz
b. Power Rating: 1/20 HP
c. Voltage: 115 V
d. Motor Type: Shaded Pole
e. Frame Material: Aluminum
f. Bearing Type: Sleeve
g. Enclosure Type: Open
h. RPM: 1550
i. Mounting Type: Foot-mounted
j. Weight: 5.5 lbs
k. Amperage: 1.2 A
l. Noise Level: 45 dB
m. Dimensions: 6.5 x 5.5 x 4.5 inches
n. Airflow: 150 CFM

Applications Used:
a. HVAC systems
b. Exhaust fans
c. Small appliances
